Putting Posgresql Data in Motion with Kafka-connect and Debezium
Change Data Capture (CDC) is a design pattern that allows you to capture changes in a database and propagate them to other systems. It is often used in event-driven architectures to keep data in sync across different services.
Architecture
The architecture consists of a PostgreSQL database, a Kafka cluster, and a Kafka-connect cluster with the Debezium connector. The Debezium connector captures changes in the PostgreSQL database and sends them to a Kafka topic. Other services can then consume the changes from the Kafka topic.
My Reference Architecture diagram
The Image-1 bellow, shows the base architecture used for most of companies that I have worked with. It is a simplified architecture that can be used for most of the companies. Operational view and Analytical view are separated.
Image-1: Simplified architecture for CDC with PostgreSQL, Kafka, and Debezium
Technology stack
This is a fully open-source and open-standard toolset for running CDC:
- Docker Compose for local development and testing
- PostgreSQL as the source database
- Kafka as the event streaming platform
- Kafka-connect with Debezium connector for change data capture (CDC)
- AKHQ for Kafka topic management and monitoring
Repository with demo project
All the components are open-source and can be run on any cloud provider or on-premises. The technology. I will not list here because everything will be in the code repository.
https://github.com/drr00t/my-data-in-motion-tech-stack
Disclaimer: This repository is a work in progress and is not a recommendation and I will do not provide a full documentation about configuration options. My idea with this it’s to provide some glance of how to use the technology stack and how to put it together.
